tvheadend

8837853a-ls288

tvheadend works as a proxy server: is a TV streaming server and recorder for Linux, FreeBSD and Android supporting DVB-S, DVB-S2, DVB-C, DVB-T, ATSC, ISDB-T, IPTV, SAT>IP and HDHomeRun as input sources. Tvheadend offers the HTTP (VLC, MPlayer), HTSP (Kodi, Movian) and SAT>IP streaming. Multiple EPG sources are supported (over-the-air DVB and ATSC including OpenTV DVB extensions, XMLTV, PyXML).

Media Tools

docker pull lscr.io/linuxserver/tvheadend:latest

Quick start

Generated from the image's own configuration. Replace the /path/to folders with real paths on your host.

Include optional settings

---
services:
  tvheadend:
    image: lscr.io/linuxserver/tvheadend:latest
    container_name: tvheadend
    environment:
      - PUID=1000
      - PGID=1000
      - TZ=Etc/UTC
      - RUN_OPTS= # optional
    volumes:
      - /path/to/tvheadend/data:/config
      - /path/to/recordings:/recordings
    ports:
      - 9981:9981
      - 9982:9982
    devices:
      - /dev/dri:/dev/dri # optional
      - /dev/dvb:/dev/dvb # optional
    restart: unless-stopped

Parameters

Ports
Port	Function	Required
9981:9981	WebUI	required
9982:9982	HTSP server port.	required

Environment variables
Variable	Function	Required
PUID=1000	User ID	required
PGID=1000	Group ID	required
TZ=Etc/UTC	Timezone	required
RUN_OPTS=	Optionally specify additional arguments to be passed. See Additional runtime parameters.	optional

Volumes
Path	Function	Required
/config	Where TVHeadend show store it's config files.	required
/recordings	Where you want the PVR to store recordings.	required

Devices
Device	Function	Required
/dev/dri	Only needed if you want to use your AMD/Intel GPU for hardware accelerated video encoding (vaapi).	optional
/dev/dvb	Only needed if you want to pass through a DVB card to the container. If you use IPTV or HDHomeRun you can leave it out.	optional

Architectures

Pulling :latest picks the right one for your host automatically.

x86_64amd64-latest
arm64arm64v8-latest

Changelog

25 Jun 2024
Rebase to Alpine 3.20.
20 Mar 2024
Rebase to Alpine 3.19.
16 Oct 2023
Add mesa-va-gallium package for AMD transcoding.
